In Stock and Arriving Soon - Professional Grade Firewood Splitters - Wolfe Ridge Firewood Splitters
Images are of our production units that may have optional equipment installed not included in the base unit.
Arriving in November 2026 - Versa-Split 1724 - Black w/ Hose Extensions
- Tech Specs
- Sideways mounted offset design for good visibility on a skid steer OR tractor!
- Heavy duty design, pick up and split those large logs easily!
- 8” reinforced H beam – In-house welded / fabricated
- 1” thick pusher with grade 8 hardware
- Replaceable bronze “Self-Lube” brand slides on push block
- Multiple configurations available:
- 1724 = 17 tons and 24 inch stroke
- 2224 = 22 tons and 24 inch stroke
- 2824 = 28 tons and 24 inch stroke PLUS Magnum big bore cylinder and tall push block
- 3030 = 30 tons and 30 inch stroke PLUS Magnum big bore cylinder and tall push block
- Magnum package is standard on the Versa Split 2824 and 3030, but not available on the 1724 or 2224
- Removable 4 way wedge included
- Universal quick attach plate = SSQA (call for other options)
- Optional bolt-on mini skid attachment plate available!
- Select SSQA with mini-skid attachment plate
- Flat face hydraulic couplers included
- Gates brand hoses with swivel hydraulic fittings
- Included hoses work with most tractors
- *For added hose length / skid steer use – add the optional hose extension set*
- 12” AR400 main wedge welded through the beam
- Heavy duty welded cylinder rated for 3500 PSI
- 82″ x 46″ x 20″ overall size for 1724 / 2224
- Shipping weight for 1724 / 2224: 500 lb
Models - Arriving in November 2026 - Versa-Split 1724 - Black w/ Hose Extensions
Versa Split 1724 Skid Steer Log Splitter - 17 Tons 24" stroke
$3,395.00
Add to Cart
The new Versa Split from Wolfe Ridge is a sideways mounted skid steer splitter that can also be used on smaller compact tractors. SSQA mounting plate is standard and it comes with hoses and flat face quick connect hydraulic couplers. Break down huge rounds without breaking your back with a Versa Split from Wolfe Ridge.
Standard configuration builds of the Versa Split have the split chamber offset to the left. This means if you are sitting in the tractor or skid steer, you will look over to the left to see the splitting action. This configuration is what you see in the photos on this product page. We can build it the opposite way as well, just choose right offset instead of left at the time of ordering.
